65 Rev.B
DYNAMIC INDICATION OF SEAT HEAT
NOTE
All functions related to the air conditioning are only status indications. It’s not possible to operate
the air conditioning with the ZENEC system.
The effective range of functions is depending on the vehicle manufacturer, vehicle type and
vehicle configuration. The ZENEC system supports all listed functions above. Differences from
this information, features or functions cannot be used for claims.
Seat heater
Indication of current seat heating level.
In addition to the digit, the seat heating level will be indicated in
three different colour gradations.
Setting
The seat heating level will be displayed in combination with a
digit.
Function Icon Operation
Temperature
arrows
Indication of actual air flow:
Frontwindow – Center – Leg room
Temperature
Blue ca. LOW – 20.0 C
Yellow ca. 20.0 – 24.0 C
Red ca. 24.0 – HIGH
Ventilator setting
The digit shows the fan level.
