Chapter16MPLSServiceConguration

16.5.2ConfiguringtheVLLResilience

VLLresilienceenhancesthestabilityandreliabilityofMPLSnetwork.

NetworkingDiagram

Figure16-26showsthenetworkingdiagramoftheVLLresilience.

Figure16-26NetworkingDiagramofVLLResilience

ThePWredundancygroupworksineither1:1or1+1mode.

lIn1:1mode,onlytheactivePWforwardstheusertrafc.

lIn1+1mode,bothPWsforwardtheusertrafc.

ThenetworksupportstheOSPFandLDPprotocols.

CongurationData

Table16-13liststhecongurationdataoftheVLLresilience.

Table16-13CongurationDataofVLLResilience

ItemData

LoopbackinterfacelID:1

lIPaddress:1.1.1.1/32

L3interface1lVLANID:10

lInterface:gei_1/21/1

lIPaddress:30.1.1.1/24

L3interface2lVLANID:11

lInterface:gei_1/21/2

lIPaddress:10.1.1.2/24

C300-1

16-87

SJ-20130520164529-007|2013-06-30(R1.0)ZTEProprietaryandCondential
