ZXA10C300CongurationManual(CLI)
ItemData
VoIPservicePort:pots_0/1
SIPprole:sip-test
UserID:12345
Username:12345
Password:12345
CongurationFlowchart
Figure2-4showsthecongurationowchartoftheGPONvoiceservice.
Figure2-4CongurationFlowchartoftheGPONVoiceService
Steps
1.InONUinterfacecongurationmode,conguretheT-CONT.
ZXAN(config)#interfacegpon-onu_1/5/1:1
ZXAN(config-if)#tcont3namevoipprofile2M
2.ConguretheGEMport.
ZXAN(config-if)#gemport3namegemport3tcont3
ZXAN(config-if)#exit
3.Inuplinkinterfacecongurationmode,conguretheuplinkportVLAN.
ZXAN(config)#interfacegei_1/22/1
ZXAN(config-if)#switchportvlan300tag
ZXAN(config-if)#exit
2-24
