Chapter 7 Connection Status
VMG/EMG/AM/DM/GM Series User’s Guide
178
Figure 80 LAN
Click the Arrow icon ( ) to configure the LAN IP settings and DHCP setting for your Zyxel Device.
Figure 81 LAN Setup
Each field is described in the following table.
Table 29 LAN Setup
LABEL DESCRIPTION
LAN IP Setup
IP Address Enter the LAN IPv4 IP address you want to assign to your Zyxel Device in dotted decimal
notation, for example, 192.168.1.1 (factory default).
Subnet Mask Enter the subnet mask of your network in dotted decimal notation, for example
255.255.255.0 (factory default). Your Zyxel Device automatically computes the subnet mask
based on the IP Address you enter, so do not change this field unless you are instructed to
do so.
IP Addressing Values
Beginning IP
Address
This field specifies the first of the contiguous addresses in the IP address pool.
Ending IP
Address
This field specifies the last of the contiguous addresses in the IP address pool.
