Chapter 2 Hardware
VMG/EMG/AM/DM/GM Series User’s Guide
43
2.1.8 GM4100-B0
Figure 24 GM4100-B0
The following are the LED descriptions of your GM4100-B0.
LAN1~4 Green On The Zyxel Device has a successful 10/100/1000 Mbps Ethernet connection
with a device on the Local Area Network (LAN).
Blinking The Zyxel Device is sending or receiving data to/from the LAN at 10/100/
1000 Mbps.
Off The Zyxel Device does not have an Ethernet connection with the LAN.
Table 9 AM3100-B0 LED Descriptions (continued)
LED COLOR STSTUS DESCRIPTION
Table 10 GM4100-B0 LED Descriptions
LED COLOR STATUS DESCRIPTION
POWER Green On The Zyxel Device is receiving power and ready for use.
Blinking The Zyxel Device is booting up.
Red On The Zyxel Device detected an error while self-testing, or there is a device
malfunction.
Blinking The Zyxel Device is uploading firmware.
Off The Zyxel Device is not receiving power.
