Chapter 9 Wireless
VMG/EMG/AM/DM/GM Series User’s Guide
228
Figure 111 Network Setting > Wireless > Channel Status
The following table describes the labels in this screen.
9.9 WLAN Scheduler
Use the WLAN Scheduler screen to create rules to schedule the times to permit Internet traffic from each
WiFi network interfaces. Select a specific time and day of a week for scheduling. You can also create a
rule to automatically switch off all the WLAN together.
Click Network Setting > Wireless > WLAN Scheduler.
Table 53 Network Setting > Wireless > Channel Status
LABEL DESCRIPTION
Channel Monitor
Scan WiFi LAN
Channels
Click the Scan button to scan WiFi channels.
Channel Scan
Result
This displays the results of the channel scan.
The blue bar displays the number of access points (AP count) in the WiFi channel.
The orange bar displays the WiFi channel that the Zyxel Device is now using.
