ZyXEL Communications N4100 User Manual

Chapter 14 Pass Through
N4100 User’s Guide
144
Note: Pass through has priority over filtering.
Figure 74 ADVANCED > PASS THROUGH
The following table describes the labels in this screen.
Table 29 ADVANCED > PASS THROUGH
LABEL DESCRIPTION
Pass Through Enable pass through to allow all users to access specific web sites (or IP
addresses) and/or allow packets from specific computers to go through
the N4100 without prompting for a user name and password.
Please enter new pass through for destination (up to 50 entries)
The destinations should be on the WAN.
URL or
Website
Select this option to allow users to access a website without entering a
user name or password.
Enter the URL (up to 350 ASCII characters) of the web site to which you
want to allow access.
Start / End IP
Address
Select this option to allow users to access a range of IP addresses
without entering a user name or password.
Enter the beginning and ending IP addresses in dotted decimal notation.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
