ZyXEL Communications N4100 User Manual

Chapter 35 Product Specifications
N4100 User’s Guide
257
Certifications
The following list, which is not exhaustive, illustrates the standards supported in
the N4100.
External Antenna Three 2dBi (Max) Dual detachable diversity antennas with reverse
SMA connectors
Power Requirement External Power Adapter
Input: 100-240 VAC, 50/60 Hz, 0.5 A
Output: 12 VDC, 1.5A
Dimensions Size: 212.5 (L) x 138.5(W) x 52.0(H) mm
Net Weight: 508g
Environment
Conditions
Operating Temperature:0 to 50
o
C
Storage Temperature: -20 to 60
o
C
Humidity: Max. 95% non-condensing
Mounting Desktop
Wall mounted
LED Indicators One PWR LED
One SYS LED
One WLAN Link/Activity LED
One WAN Link/Activity LED
Four LAN Link/Activity LEDs
Table 67 Hardware Specifications
Table 68 Certifications
Certifications FCC part 15 Class B
CE / R&TTE
C-Tick
IC RSS-210
Table 69 Standards Supported
STANDARD DESCRIPTION
RFC 1058 RIP-1 (Routing Information Protocol)
RFC 1112 IGMP v1
RFC 1305 Network Time Protocol (NTP version 3)

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
