ZyXEL Communications N4100 User Manual

Chapter 35 Product Specifications
N4100 User’s Guide
260
Make sure that the Ethernet cable connection between the ZyAIR and a computer
or switch uplink port conforms to the following pin assignments.
CONSOLE Port
The N4100 does not currently use this port.
Antenna Connector Type
The N4100 is equipped with reverse polarity SMA jacks.
Antenna Specifications
2.4 GHz wireless antennas with reverse polarity SMA plugs are included.
3 Output Transmit Data + TD+
4Unused N/U
5Unused N/U
6 Output Transmit Data - TD-
7Unused N/U
8Unused N/U
Table 74 LAN Port Cable Pin Assignments
ETHERNET DEVICE
(COMPUTER/ UPLINK PORT)
N4100
1 TD+ 1 RD+
2 TD- 2 RD-
3RD+ 3 TD+
6RD- 6 TD-
Table 73 LAN Port Cable Pin Assignments
PIN NO RJ-45 SIGNAL ASSIGNMENT DESIGNATION

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
