The Table 14 below lists all the hardware units which can be configured in Control
Builder under CI873.
Table 14. Table showing all the Hardware units
Name Description Icon
Hardware
Position (Root.
Allowed
position)
Device Status
Reported to
User
Has IO
Channels
CI873 Communication
Interface for
EtherNet/IP
PM,
Pos:1-12
Ye s N o
CI873
Scanner
Diagnostics
Diagnostics of
CI873
EtherNet/IP
Scanner
CI873,
Pos: 254
No Yes
LD800DN Linking Device
for DeviceNet
devices
CI873,
Pos: 1-253 but
max of 4
Instances
Ye s N o
LD800DN
Diagnostics
Diagnostics of
LD800DN
LD800DN,
Pos: 64
No Yes
EtherNet/IP
Devices
(1)
See Note
(2)
CI873,
Pos: 1-253
Ye s Ye s
DeviceNet
Device
(1)
See Note
(2)
LD800DN,
Pos : 1-63
Ye s Ye s
EtherNet/IP
Modular
Adapter
(1)
See Note
(2)
CI873,
Pos: 1-253
Ye s N o
