I/O
Connection-
O -> T RPI
Dint ms 10 500 Editable Requested Packet Interval in
milliseconds for O -> T packets. The
value is used to allocate bandwidth at
each of the producing nodes (CI873)
CI873 re-establishes the connection
with the Linking Device. The
bandwidth is allotted to the new value
by the CI873. The default value is
10ms.
Upon modification, communication of
CI873 with all DeviceNet devices is
stopped till the connection is re-
established.
I/O
Connection
- T -> O RPI
Dint ms 10 500 Editable Requested Packet Interval in
milliseconds for T -> O packets
Measures how frequently CI873
requires the transmission of data
from the linking device. The default
value is 10ms.
Upon modification, CI873
re-establishes the connection with
linking device. Communication of
CI873 with all DeviceNet devices is
stopped till the connection is

re-established.
Table 17. Settings for LD 800DN Linking Device Unit (Continued)
Parameter Data Type Unit Min Max
Editable
/Read
Only
Description
