Tabl e 22. Cyclic Connection Parameters
Parameter
Default
Value
Data
Type
Read Only /
Editable
Description
Acknowledge
time
16 Int Editable It is the amount of time that a producing
node (a DeviceNet slave) waits for an
acknowledgement from the consuming node
(a linking device LD 800DN) before it re-
sends the data.
Send Rate 1000 ms Int Editable This is the background production interval
for cyclic connection. If 1000ms is the Send
Rate, then the device cyclically produces
data every 1000ms.
Inhibit time 1 ms Int Editable This is the new data production inhibit time.
If it is set as 1ms, then the slave produces
the data after every 1ms, even if it has new
data ready before this time elapses.
Cyclic
Connection
Enabled
Depends
on the
device
support
as stated
in its EDS
file
Enum Editable Enable or disable the connection. If enabled,
linking device communicates with the device
over the Cyclic connection
Values are: Enabled and Disabled.
