ABB AC 800M

Section 4 Configuration Configuring S200 I/O Modules
9ARD000014-600 A 155
CtrlSig In 1 Bit 00 0 - Not Used
Bit 01 0 - Not Used
Bit 02 0 - Not Used
Bit 03 0 - Not Used
Bit 04 Status for input A (pulse transmitter 1) - This bit, when set,
indicates a signal at A
Bit 05 Status for input B (pulse transmitter 1) - This bit, when set,
indicates a signal at B
Bit 06 Status for input Z (pulse transmitter 1) - This bit, when set,
indicates a signal at Z
Bit 07 Status for input G (pulse transmitter 1) - This bit, when set,
indicates a signal at G
Bit 09 (11) This bit, when set (1), indicates that counter 1 has been calibrated.
This bit is reset by CalReset.
Bit 11 (13) This bit, when set (1), indicates a counter value is saved in store 1.
This bit is reset by StoreReset.
Bit 13 (15) Preset Reached - When this bit is set (1), in all configuration
modes, the counter 1 value equals the preset 1 value, either in a
positive or negative direction. This bit is reset by PresetReset1 and
can only be set again after at least 1 more pulse.
Bit 15 (17) Count Direction - Increase/Decrease counter value of counter 1 set
to 0 at startup.
0 = last pulse decreased counter value;
1 = last pulse increased counter value.
Latch In 0 Bits 00-15 Saved counter value on channel 0
Latch In 1 Bits 00-15 Saved counter value on channel 1
Value In 0 Bits 00-15 Current value in counter 0
Table 27. Description of Channels for 200-IP2 (Continued)
Channel Name Bit Definition
