ABB AC 800M

Configuring S200 I/O Modules Section 4 Configuration
162 9ARD000014-600 A
Function Select Bits 00 Pulse counting and period time measurement selection for
Channel 0 -
0 = pulse counting and period time measurement selected
1 = period time measurement selected
Bits 01 Pulse counting and period time measurement selection for
Channel 1 -
0 = pulse counting and period time measurement selected
1 = period time measurement selected
Bits 02 Pulse counting and period time measurement selection for
Channel 2 -
0 = pulse counting and period time measurement selected
1 = period time measurement selected
Bits 03 Pulse counting and period time measurement selection for
Channel 3 -
0 = pulse counting and period time measurement selected
1 = period time measurement selected
Bits 04-15 Reserved
Table 28. Description of Channels for 200-IP4 (Continued)
Channel Name Definition
