ABB AC 800M

Section 4 Configuration Configuring S200 I/O Modules
9ARD000014-600 A 161
Ctrl In 0 Bit
Bit 00 Positive edge - Channel 0 - measurement ready
Bit 04 Reset Done, Channel 0 - a positive edge on this bit indicates
counter 0 reset done
Ctrl In 1 Bit
Bit 01 Positive edge - Channel 1 - measurement ready
Bit 05 Reset Done, Channel 1 - a positive edge on this bit indicates
counter 1 reset done
Ctrl In 2 Bit
Bit 02 Positive edge - Channel 2 - measurement ready
Bit 06 Reset Done, Channel 2 - a positive edge on this bit indicates
counter 2 reset done
Ctrl In 3 Bit
Bit 03 Positive edge - Channel 3 - measurement ready
Bit 07 Reset Done, Channel 3 - a positive edge on this bit indicates
counter 3 reset done
Bit 08-15 Reserved for factory use
Table 28. Description of Channels for 200-IP4 (Continued)
Channel Name Definition
