ABB AC 800M

Appendix A Troubleshooting EDS File
230 9ARD000014-600 A
23 Connection Path for
<connection name>
connection is not
as per CIP
standard. Please
retry with the
correct EDS file
Connection Path in
Connection
Manager section is
invalid and not as
per CIP
specification in EDS
file
General Purpose
Device
EtherNet/IP
Import will abort. 
Contact the vendor to
get device EDS files
with all the valid
entries.
24 Device
Classification
section is faulty.
Retry with correct
EDS file
The EDS file does
not have device
classification field to
classify it as
DeviceNet or
EtherNet/IP
DeviceNet/
Modular
Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields.
25 Descriptor field of
Param Class section
is not present.
Please retry with
correct EDS file.
Descriptor field of
param class section
in EDS file is empty.
General Purpose
Device
EtherNet/IP/
DeviceNet
Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields with non-empty
entries.
26 Member size and
Member reference of
assembly entry
cannot be null
together. Please
retry with a
correct EDS file
If the member size
and member
reference fields of
assembly section in
EDS file is empty.
Modular
EtherNet/IP/
DeviceNet
Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields without any
empty entries.
Table 41. Messages - Import of EDS Files (Continued)
Sl
No
Message Reason
Applicability
Based on Device
Classification
Additional
Information and
Workaround
