ABB AC 800M

Appendix A Troubleshooting EDS File
9ARD000014-600 A 231
27 Member size and
Member reference of
assemExa entry
cannot be null
together. Please
retry with a
correct EDS file
If the member size
and member
reference fields of
assemExa section
in EDS file is null
General Purpose
Device DeviceNet
Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields without any
empty entries.
28 Variant entries are
not as per
standard. Please
retry with correct
EDS file
If some entries in
variant field is
empty in the EDS
file. For example:
selector, value,
entry etc.
General Purpose
Device
EtherNet/IP/
DeviceNet
Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields with non-empty
entries.
29 CfgAssembly field
is not as per
specifications.
Please retry with
correct EDS file.
Config assembly
field of EDS file is
empty.
DeviceNet Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields with non-empty
entries.
30 There is a problem
in parsing of
files, please refer
the Log for more
information.
Refer the DIW log
file for information
EtherNet/IP/
DeviceNet
Import will abort.
Refer the DIW log file
for information.
31 The 'size' field in
the Producing
Connection Entry is
null. Please retry
with a valid EDS
file.
Size field of
producing
connection in EDS
file is null
DeviceNet Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields without any
empty entries.
Table 41. Messages - Import of EDS Files (Continued)
Sl
No
Message Reason
Applicability
Based on Device
Classification
Additional
Information and
Workaround
