ABB AC 800M

Appendix A Troubleshooting EDS File
234 9ARD000014-600 A
40 The 'help string'
field in the
Producing
Connection Entry is
null. Please retry
with a valid EDS
file.
The help string field
in producing
connection of IO
info section is null.
DeviceNet Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields without any
empty entries.
41 Invalid Epath in
assembly section.
Do you want to
continue?
Epath field in assem
section of EDS file
has invalid entry.
Modular
EtherNet/IP/
DeviceNet
Continue the import
with this message.
Else, import will be
aborted, and contact
the vendor to get
device EDS files with
all the valid entries.
42 Invalid size in
assembly section.
Do you want to
continue?
Size field in assem
section of EDS file
has invalid entry
Modular
EtherNet/IP/
DeviceNet
Continue the import
with this message.
Else, import will be
aborted, and contact
the vendor to get
device EDS files with
all the valid entries.
43 Invalid descriptor
in assembly
section. Do you
want to continue?
Descriptor field in
assem section of
EDS file has invalid
entry
Modular
EtherNet/IP/
DeviceNet
Continue the import
with this message.
Else, import will be
aborted and contact
the vendor to get
device EDS files with
all the valid entries.
Table 41. Messages - Import of EDS Files (Continued)
Sl
No
Message Reason
Applicability
Based on Device
Classification
Additional
Information and
Workaround
