Parameters 167
22.24 Constant speed sel3 When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 3.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.22
Constant speed sel1 and 22.23 Constant speed sel2
select three sources that are used to activate constant
speeds. See table at parameter 22.22 Constant speed
sel1.
For the selections, see parameter 22.22 Constant speed
sel1.
Always off
22.26 Constant speed 1 Defines constant speed 1 (the speed the motor will turn
when constant speed 1 is selected).
300.00 rpm
-30000.00… 30000.00
rpm
Constant speed 1. See par.
46.01
22.27 Constant speed 2 Defines constant speed 2. 600.00 rpm
-30000.00… 30000.00
rpm
Constant speed 2. See par.
46.01
22.28 Constant speed 3 Defines constant speed 3. 900.00 rpm
-30000.00… 30000.00
rpm
Constant speed 3. See par.
46.01
22.29 Constant speed 4 Defines constant speed 4. 1200.00 rpm
-30000.00… 30000.00
rpm
Constant speed 4. See par.
46.01
22.30 Constant speed 5 Defines constant speed 5. 1500.00 rpm
-30000.00… 30000.00
rpm
Constant speed 5. See par.
46.01
22.31 Constant speed 6 Defines constant speed 6. 2400.00 rpm
-30000.00… 30000.00
rpm
Constant speed 6. See par.
46.01
22.32 Constant speed 7 Defines constant speed 7. 3000.00 rpm
-30000.00… 30000.00
rpm
Constant speed 7. See par.
46.01
22.41 Speed ref safe Defines a safe speed reference value that is used with
supervision functions such as
• 12.03 AI supervision function
• 49.05 Communication loss action
0.00 rpm
-30000.00… 30000.00
rpm
Safe speed reference. See par.
46.01
22.42 Jogging 1 ref Defines the speed reference for jogging function 1. For
more information on jogging, see page 58.
0.00 rpm
-30000.00… 30000.00
rpm
Speed reference for jogging function 1. See par.
46.01
22.43 Jogging 2 ref
Defines the speed reference for jogging function 2. For
more information on jogging, see page 58.
0.00 rpm
-30000.00… 30000.00
rpm
Speed reference for jogging function 2. See par.
46.01
No. Name/Value Description Default
FbEq 16
