166 Parameters
22.22 Constant speed sel1 When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 1.
Note: The default value depends on the selected macro.
See Control macros on page 27.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.23
Constant speed sel2 and 22.24 Constant speed sel3
select three sources whose states activate constant
speeds as follows:
DI3
Always off 0 (always off). 0
Always on 1 (always on). 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
22.23 Constant speed sel2 When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 2.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.22
Constant speed sel1 and 22.24 Constant speed sel3
select three sources that are used to activate constant
speeds.
For the selections, see parameter
22.22 Constant speed
sel1.
Note: The default value depends on the selected macro.
See Control macros on page 27.
DI4
No. Name/Value Description Default
FbEq 16
Source defined
by par. 22.22
Source defined
by par. 22.23
Source defined
by par. 22.24
Constant speed active
000 None
1 0 0 Constant speed 1
0 1 0 Constant speed 2
1 1 0 Constant speed 3
0 0 1 Constant speed 4
1 0 1 Constant speed 5
0 1 1 Constant speed 6
1 1 1 Constant speed 7
