224 Parameters
Ni1000 Ni1000 sensor connected to the analog input selected by
parameter 35.14 Temperature 1 AI source and an analog
output.
The following settings are required:
• Set the hardware jumper or switch related to the analog
input to U (voltage). Any change must be validated by a
control unit reboot.
• Set the appropriate analog input unit selection
parameter in group 12 Standard AI to V (volt).
• In parameter group 13 Standard AO, set the source
selection parameter of the analog output to Temp
sensor 1 excitation.
The analog output feeds a constant current through the
sensor. As the resistance of the sensor increases along
with its temperature, the voltage over the sensor
increases. The voltage is read by the analog input and
converted into degrees.
16
PTC analog I/O
PTC sensor connected to analog input selected by
parameter 35.14 Temperature 1 AI source and an analog
output.
The required settings are the same as with selection
KTY84 analog I/O.
Note: With this selection, the control program converts the
analog signal to PTC resistance value in ohms and shows
it in parameter 35.02. The parameter name and unit still
refer to temperature.
20
35.12 Temperature 1 fault
limit
Defines the fault limit for temperature supervision
function 1. The unit is selected by parameter 96.16 Unit
selection.
Note: With a PTC sensor, the unit is ohms.
130 °C, or
266 °F or
4500 ohm
-60…5000 °C, or
-76…9032 °F, or
0...5000 ohm
Fault limit for temperature monitoring function 1. 1 = 1 unit
35.13 Temperature 1
warning limit
Defines the warning limit for temperature supervision
function 1. The unit is selected by parameter 96.16 Unit
selection.
Note: With a PTC sensor, the unit is ohms.
110 °C, or
230 °F or
4000 ohm
-60…5000 °C, or
-76…9032 °F, or
0...5000 ohm
Warning limit for temperature monitoring function 1. 1 = 1 unit
35.14 Temperature 1 AI
source
Selects the input for parameter 35.11 Temperature 1
source selections 1 x Pt100 analog I/O, 2 x Pt100 analog
I/O, 3 x Pt100 analog I/O, and Direct temperature.
Not selected
Not selected None. 0
AI1 actual value Analog input AI1. 1
AI2 actual value Analog input AI2. 2
Other Source selection (see Terms and abbreviations
). -
No. Name/Value Description Default
FbEq 16
