240 Parameters
40.21 Set 1 internal setpoint
1
Internal process setpoint 1. See parameter 40.19 Set 1
internal setpoint sel11.
0.00 PID
customer
units
-200000.00…
200000.00 PID
customer units
Internal process setpoint 1. 1 = 1 PID
customer
unit
40.22 Set 1 internal setpoint
2
Internal process setpoint 2. See parameter 40.19 Set 1
internal setpoint sel1.
0.00 PID
customer
units
-200000.00…
200000.00 PID
customer units
Internal process setpoint 2. 1 = 1 PID
customer
unit
40.23 Set 1 internal setpoint
3
Internal process setpoint 3. See parameter 40.19 Set 1
internal setpoint sel1.
0.00 PID
customer
units
-200000.00…
200000.00 PID
customer units
Internal process setpoint 3. 1 = 1 PID
customer
unit
40.24 Set 1 internal setpoint
0
Internal process setpoint 0. See parameter 40.19 Set 1
internal setpoint sel1.
0.00 PID
customer
units
-200000.00…
200000.00 PID
customer units
Internal process setpoint 0. 1 = 1 PID
customer
unit
40.26 Set 1 setpoint min Defines a minimum limit for the process PID controller
setpoint.
0.00
-200000.00…
200000.00
Minimum limit for process PID controller setpoint. 1 = 1
40.27 Set 1 setpoint max Defines a maximum limit for the process PID controller
setpoint.
200000.00
-200000.00…
200000.00
Maximum limit for process PID controller setpoint. 1 = 1
40.28 Set 1 setpoint increase
time
Defines the minimum time it takes for the setpoint to
increase from 0% to 100%.
0.0 s
0.0…1800.0 s Setpoint increase time. 1 = 1
40.29 Set 1 setpoint
decrease time
Defines the minimum time it takes for the setpoint to
decrease from 100% to 0%.
0.0 s
0.0…1800.0 s Setpoint decrease time. 1 = 1
40.30 Set 1 setpoint freeze
enable
Freezes, or defines a source that can be used to freeze,
the setpoint of the process PID controller. This feature is
useful when the reference is based on a process feedback
connected to an analog input, and the sensor must be
serviced without stopping the process.
1 = Process PID controller setpoint frozen
See also parameter 40.38 Set 1 output freeze enable
Not selected
Not selected Process PID controller setpoint not frozen. 0
Selected Process PID controller setpoint frozen. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
No. Name/Value Description Default
FbEq 16
