Additional parameter data 327
71.35 Derivation filter time Real 0.0…10.0 s 10 = 1 s
71.36 Output min Real -200000.00…200000.00 - 10 = 1
71.37 Output max Real -200000.00…200000.00 - 10 = 1
71.38 Output freeze enable Binary src --1 = 1
71.39 Deadband range Real 0.0…200000.0 - 10 = 1
71.40 Deadband delay Real 0.0...3600.0 s 10 = 1 s
71.58 Increase prevention List 0…3 - 1 = 1
71.59 Decrease prevention List 0…3 - 1 = 1
71.62 Internal setpoint actual Real -200000.00…200000.00 rpm,% or
Hz
100 = 1 unit
71.79 External PID units Real -200000.00…200000.00 rpm,% or
Hz
100 = 1 unit
95 HW configuration
95.01 Supply voltage List 0…5 - 1 = 1
95.02 Adaptive voltage limits List 0…1 - 1 = 1
95.03 Estimated AC supply voltage Real 0…65535 - 1 = 1 V
95.20 HW options word 1 PB 0000h…FFFFh - 1 = 1
95.26 Motor disconnect detection List 0...1 - 1 = 1
95.200 Cooling fan mode PB 0000h…FFFFh - 1 = 1
96 System
96.01 Language List --1 = 1
96.02 Pass code Data 0…99999999 - 1 = 1
96.03 Access levels status PB 0b0000...0b1111 - 1 = 1
96.04 Macro select List 0, 1, 5, 8, 9, 12...14 - 1 = 1
96.05 Macro active List 0, 1, 5, 8, 9, 12...14 - 1 = 1
96.06 Parameter restore List 0, 8, 62 - 1 = 1
96.07 Parameter save manually List 0…1 - 1 = 1
96.08 Control board boot Real 0…1 - 1 = 1
96.10 User set status List 0…7, 20…23 - -
96.11 User set save/load List 0…5, 18…21 - -
96.12 User set I/O mode in1 Binary src ---
96.13 User set I/O mode in2 Binary src ---
96.16 Unit selection PB 0b0000...0b1111 - 1 = 1
96.51 Clear fault and event logger Real 0...1 - 1 = 1
96.54 Checksum action List 0...4 - 1 = 1
96.55 Checksum control word PB 0b0000...0b1111 - 1 = 1
96.68 Actual checksum A Real 0x0000...0xffff - 1 = 1
96.69 Actual checksum B Real 0x0000...0xffff - 1 = 1
96.71 Approved checksum A Real 0x0000...0xffff - 1 = 1
96.72 Approved checksum B Real 0x0000...0xffff - 1 = 1
96.78 550 compatibility mode List 0...1 - 1 = 1
No. Name Type Range Unit FbEq32
