328 Additional parameter data
(Parameters 96.100…96.102 only visible when enabled by parameter 96.02)
96.100 Change user pass code Data 10000000…99999999 - 1 = 1
96.101 Confirm user pass code Data 10000000…99999999 - 1 = 1
96.102 User lock functionality PB 0000h…FFFFh - 1 = 1
97 Motor control
97.01 Switching frequency
reference
List 4…12 kHz 1 = 1
97.02 Minimum switching frequency List 1…12 kHz 1 = 1
97.03 Slip gain Real 0…200 % 1 = 1%
97.04 Voltage reserve Real -4…50 % 1 = 1%
97.05 Flux braking List 0…2 - 1 = 1
97.06 Flux reference select Binary src --1 = 1
97.07 User flux reference Real 0.0...200.0 % 100 = 1%
97.08 Optimizer minimum torque Real 0.0...1600.0 % 10 = 1%
97.11 TR tuning Real 25…400 % 1 = 1%
97.13 IR compensation Real 0.00…50.00 % 100 = 1%
97.15 Motor model temperature
adaptation
List 0...1 - 1 = 1
97.16 Stator temperature factor Real 0...200 % 1=1%
97.17 Rotor temperature factor Real 0...200 % 1=1%
97.20 U/F ratio List 0…1 - 1 = 1
97.33 Speed estimate filter time Real 0.00...100.00 - 1 = 1
97.48 Udc stabilizer List 0, 50, 100, 300, 500, 800 % 1 = 1%
97.49 Slip gain for scalar Real 0...200 % 1 = 1%
97.94 IR comp max frequency Real 1.0...200.0 % 10 = 1%
97.135 Udc ripple Real 0.0...200.0 V 10 = 1V
98 User motor parameters
98.01 User motor model mode List 0…1 - 1 = 1
98.02 Rs user Real 0.0000…0.50000 p.u. 100000 = 1
p.u.
98.03 Rr user Real 0.0000…0.50000 p.u. 100000 = 1
p.u.
98.04 Lm user Real 0.00000…10.00000 p.u. 100000 = 1
p.u.
98.05 SigmaL user Real 0.00000…1.00000 p.u. 100000 = 1
p.u.
98.06 Ld user Real 0.00000…10.00000 p.u. 100000 = 1
p.u.
98.07 Lq user Real 0.00000…10.00000 p.u. 100000 = 1
p.u.
98.08 PM flux user Real 0.00000…2.00000 p.u. 100000 = 1
p.u.
98.09 Rs user SI Real 0.00000…100.00000 ohm 100000 = 1
p.u.
No. Name Type Range Unit FbEq32
