Program features 149
drive runs continuously from 18:00 (6 p.m.) on Friday evening to 06:30 (6:30 a.m.) on
Monday morning. Timed function is enabled on the rising edge of digital input DI1.
Settings
Parameter Setting
3601 TIMERS ENABLE DI1 CMODE
3602 START TIME 1 18:00:00
3603 STOP TIME 1 06:30:00
3604 START DAY 1 FRIDAY
3605 STOP DAY 1 MONDAY
Parameter Additional information
36 TIMED FUNCTIONS Timed functions settings
1001, 1002 Timed start/stop control
1102 Timed EXT1/EXT2 selection
1201 Timed constant speed 1 activation
1209 Timed speed selection
1401 Timed function status indicated through relay output RO 1
1402/1403/1410 Timed function status indicated through relay output RO 2…4.
With option MREL-01 only.
1805 Timed function status indicated through digital output DO
4027 Timed PID1 parameter set 1/2 selection
4039 Selection between different internal (constant) set points for
the process PID control (PID1 parameter set 1)
4139 Selection between different internal (constant) set points for
the process PID control (PID1 parameter set 2)
4228 Timed external PID2 activation
8126 Timed Autochange activation
