258 Actual signals and parameters
SUPRV1
OVER
Trigger on SUPRV1 OVER (parameter 1401 RELAY
OUTPUT 1). See parameter group 32 SUPERVISION.
12
DRIVE START Trigger when the drive receives a start command 13
TIMER TRIG Pump cleaning sequence is started periodically at intervals
defined by parameter 4607 TRIG TIME.
14
DI1(INV) Trigger on the falling edge of digital input DI1 -1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
DI1(INV)S1O Enable on the falling edge of digital input DI1, trigger on
SUPRV1 OVER (parameter 1401 RELAY OUTPUT 1). See
parameter group 32 SUPERVISION.
-7
DI2(INV)S1O See selection DI1(INV)S1O.-8
DI3(INV)S1O See selection DI1(INV)S1O.-9
DI4(INV)S1O See selection DI1(INV)S1O.-10
DI5(INV)S1O See selection DI1(INV)S1O.-11
4602 FWD STEP Defines the forward step frequency for the pump cleaning
sequence in percent of the nominal motor frequency
(parameter 9907 MOTOR NOM FREQ).
0.0%
0.0…100.0% Forward step frequency 1 = 0.1%
4603 REV STEP Defines the reverse step frequency for the pump cleaning
sequence in percent of the nominal motor frequency
(parameter 9907 MOTOR NOM FREQ).
0.0%
0.0…100.0% Reverse step frequency 1 = 0.1%
4604 OFF TIME Defines the length of the interval between forward and
reverse steps in the pump cleaning sequence in seconds.
0.0 s
0.0…1000.0 s Off time (step interval) 1 = 0.1 s
4605 FWD TIME Defines the duration of each forward step in the pump
cleaning sequence in seconds.
0.0 s
0.0…1000.0 s Forward step duration 1 = 0.1 s
4606 REV TIME Defines the duration of each reverse step in the pump
cleaning sequence in seconds.
0.0 s
0.0…1000.0 s Reverse step duration 1 = 0.1 s
4607 TRIG TIME Defines the time for setting TIMER TRIG of parameter 4601
PUMP CLEAN TRIG.
0.0 h
0.0…200.0 h Trigger time in hours 1 = 0.1 h
4608 COUNT Number of steps to be performed in the pump cleaning
sequence.
0
0…100 Number of steps 1 = 1
52 PANEL COMM Communication settings for the control panel port on the
drive
5201 STATION ID Defines the address of the drive. Two units with the same
address are not allowed on-line.
1
1…247 Address 1 = 1
All parameters
No. Name/Value Description Def/FbEq
