ABB ACS310 - Ratings

336 Technical data
Ratings
Note: When choke is not used, input current is effected by supply network and
impedance.
Use the table in Fuses and alternate short-circuit protection (page 340) to correctly
size the input cabling as well as input fuses or MMP for branch circuit protection.
Sizing will be determined by the actual input current which is dependent on the input
line voltage and the input choke selection and rated motor current. If motor rated
current is below I
2N
, I
1N
is reduced relatively.
Type Input without
choke or
reactor
Input with
choke or 5%
reactor
Output Frame
size
ACS310- I
1N
I
1N
(480 V)
I
1N
I
1N
(480 V)
I
LD
I
2N
I
2max
P
N
x = E/U
1)
A A A A A A A kW hp
1-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
01x-02A4-2 6.1 - 4.5 - 2.3 2.4 4.0 0.37 0.5 R0
01x-04A7-2 11.4 - 8.1 - 4.5 4.7 7.9 0.75 1 R1
01x-06A7-2 16.1 - 11.0 - 6.5 6.7 11.4 1.1 1.5 R1
01x-07A5-2 16.8 - 12.0 - 7.2 7.5 12.6 1.5 2 R2
01x-09A8-2 21.0 - 15.0 - 9.4 9.8 16.5 2.2 3 R2
3-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
03x-02A6-2 4.7 - 2.6 - 2.4 2.6 4.2 0.37 0.5 R0
03x-03A9-2 6.7 - 3.6 - 3.5 3.9 6.1 0.55 0.75 R0
03x-05A2-2 8.4 - 4.8 - 4.7 5.2 8.2 0.75 1 R1
03x-07A4-2 13.0 - 7.2 - 6.7 7.4 11.7 1.1 1.5 R1
03x-08A3-2 13.2 - 8.2 - 7.5 8.3 13.1 1.5 2 R1
03x-10A8-2 15.7 - 11.0 - 9.8 10.8 17.2 2.2 3 R2
03x-14A6-2 23.9 - 14.0 - 13.3 14.6 23.3 3 3 R2
03x-19A4-2 27.3 - 18.0 - 17.6 19.4 30.8 4 5 R2
03x-26A8-2 45.0 - 27.0 - 24.4 26.8 42.7 5.5 7.5 R3
03x-34A1-2 55.0 - 34.0 - 31.0 34.1 54.3 7.5 10 R4
03x-50A8-2 76.0 - 47.0 - 46.2 50.8 80.9 11.0 15 R4
3-phase U
N
= 380…480 V (380, 400, 415, 440, 460, 480 V)
03x-01A3-4 2.4 2.0 1.3 1.1 1.2 1.3 2.1 0.37 0.5 R0
03x-02A1-4 4.0 3.3 2.0 1.7 1.9 2.1 3.3 0.55 0.75 R0
03x-02A6-4 4.5 3.8 2.5 2.1 2.4 2.6 4.2 0.75 1 R1
03x-03A6-4 6.6 5.5 3.5 2.9 3.3 3.6 5.8 1.1 1.5 R1
03x-04A5-4 7.6 6.3 3.8 3.2 4.1 4.5 7.2 1.5 2 R1
03x-06A2-4 10.6 8.8 5.3 4.4 5.6 6.2 9.8 2.2 3 R1
03x-08A0-4 12.8 10.7 6.8 5.7 7.3 8.0 12.8 3 3 R1
03x-09A7-4 15.0 12.5 8.6 7.2 8.8 9.7 15.4 4 5 R1
03x-13A8-4 20.7 17.2 12.3 10.3 12.5 13.8 21.9 5.5 7.5 R3
