Actual signals and parameters 179
REVERSE Fixed to reverse 2
REQUEST Control of rotation direction allowed 3
1011 PANEL FORCE
STOP
Enables stopping the drive from the control panel even
when not in local control.
DISABLE
DISABLE Control panel stop button is active only in local control 0
ENABLE Drive can be stopped from the control panel in remote
control
1
11 REFERENCE
SELECT
Panel reference type, external control location selection and
external reference sources and limits
1101 KEYPAD REF
SEL
Selects the type of the reference in the local control mode.
REF1(Hz/
rpm)
REF1(Hz/rpm) Frequency reference in Hz 1
REF2(%) %-reference 2
1102 EXT1/EXT2
SEL
Defines the source from which the drive reads the signal
that selects between the two external control locations,
EXT1 or EXT2.
EXT1
EXT1 EXT1 active. The control signal sources are defined by
parameters 1001 EXT1 COMMANDS and 1103 REF1
SELECT.
0
DI1 Digital input DI1. 0 = EXT1, 1 = EXT2. 1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
EXT2 EXT2 active. The control signal sources are defined by
parameters 1002 EXT2 COMMANDS and 1106 REF2
SELECT.
7
COMM Fieldbus interface as the source for EXT1/EXT2 selection,
ie Control word 0301 FB CMD WORD 1 bit 5 (with ABB
drives profile 5319 EFB PAR 19 bit 11). The Control word is
sent by the fieldbus controller through the embedded
fieldbus (Modbus) to the drive. For the Control word bits,
see sections DCU communication profile on page 307 and
ABB drives communication profile on page 302.
8
TIMED FUNC 1 Timed EXT1/EXT2 control selection. Timed function 1 active
= EXT2, timed function 1 inactive = EXT1. See parameter
group 36 TIMED FUNCTIONS.
9
TIMED FUNC 2 See selection TIMED FUNC 1.10
TIMED FUNC 3 See selection TIMED FUNC 1.11
TIMED FUNC 4 See selection TIMED FUNC 1.12
DI1(INV) Inverted digital input DI1. 1 = EXT1, 0 = EXT2. -1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
All parameters
No. Name/Value Description Def/FbEq
