276 Actual signals and parameters
DI1 Enables the Interlock function and assigns a digital input
(starting with DI1) to the interlock signal for each PFC relay.
These assignments are defined in the following table and
depend on:
• the number of PFC relays (number of parameters
1401…1403 and 1410 with value = 31 [PFC])
• the Autochange function status (disabled if 8118
AUTOCHNG INTERV = 0.0, and otherwise enabled).
1
All parameters
No. Name/Value Description Def/FbEq
No. of
PFC
relays
Autochange disabled
(Parameter 8118)
Autochange enabled
(Parameter 8118)
0 DI1: Speed reg motor
DI2…DI5: Free
Not allowed
1 DI1: Speed reg motor
DI2: First PFC relay
DI3…DI5: Free
DI1: First PFC relay
DI2…DI5: Free
2 DI1: Speed reg motor
DI2: First PFC relay
DI3: Second PFC relay
DI4…DI5: Free
DI1: First PFC relay
DI2: Second PFC relay
DI3…DI5: Free
3 DI1: Speed reg motor
DI2: First PFC relay
DI3: Second PFC relay
DI4: Third PFC relay
DI5…DI5: Free
DI1: First PFC relay
DI2: Second PFC relay
DI3: Third PFC relay
DI4…DI5: Free
4 DI1: Speed reg motor
DI2: First PFC relay
DI3: Second PFC relay
DI4: Third PFC relay
DI5: Fourth PFC relay
DI1: First PFC relay
DI2: Second PFC relay
DI3: Third PFC relay
DI4: Fourth PFC relay
DI5: Free
5 Not allowed DI1: First PFC relay
DI2: Second PFC relay
DI3: Third PFC relay
DI4: Fourth PFC relay
DI5: Fifth PFC relay
