288 Fieldbus control with the embedded fieldbus
Note: The RS-232 connection is supported from software version 4.02A onwards.
The drive can be set to receive all of its control information through the fieldbus
interface, or the control can be distributed between the fieldbus interface and other
available sources, eg digital and analog inputs.
Embedded fieldbus
(Modbus) connection
through either RS-232 or
EIA-485
Fieldbus
controller
Fieldbus
Other
devices
Process I/O (cyclic)
Service messages (acyclic)
EIA-485
I/O terminals 23…26
Drive
Data flow
Control word (CW)
References
Status word (SW)
Actual values
Parameter R/W
RS-232
panel connector
