110 Parameters
05.04 Fan on-time counter Running time of the drive cooling fan. Can be reset from
the control panel by keeping Reset down for over 3
seconds.
-
0…65535 d Cooling fan run-time. 1 = 1 d
05.10 Control board
temperature
Measured temperature of the control board. -
-100… 300 °C or °F Temperature in degrees Celsius for Fahrenheit. 1 = unit
05.11 Inverter temperature Estimated drive temperature in percent of fault limit. The
fault limit varies according to the type of the drive.
0.0% = 0 °C (32 °F)
100.0% = Fault limit
-
-40.0…160.0% Temperature in percent. 1 = 1%
05.22 Diagnostic word 3 Diagnostic word 3. See chapter Fault tracing.-
0000h…FFFFh Diagnostic word 3. 1 = 1
0…86400 s
No. Name/Value Description Default
FbEq 16
Bit Name Value
0 Main circuit pwr ON
1 Ext. pwr supply Reserved xxxxx 1 = Control board is powered on from external
power supply for example user provided 24V.
2 Programming
wand
xxxxx 1 = Control board is powered ON by the Programming wand
tool.
3 Panel port comm
loss
xxxxx 1 = Panel port communication lost.
4 Reserved
5 Field bus force trip xxxxx 1 = Fault trip forced (requested) from a fieldbus.
6 Start inhibited xxxxx 1 = Start inhibited (prevented) due to, for example, interlock.
7 Safe Torq Off xxxxx 1 = Safe Torque Off fault active.
8 STO broken xxxxx 1 = Safe Torque Off circuitry is broken. Check wiring.
9 kWh pulse 1 = kWh pulse is active.
10 Reserved
11 Fan command 1 = Drive fan is rotating above idle speed.
12…15 Reserved
