Parameters 297
Saving A user set is being saved. 2
Faulted Invalid or empty parameter set. 3
User1 IO active User set 1 has been selected by parameters 96.12 User
set I/O mode in1 and 96.13 User set I/O mode in2.
4
User2 IO active User set 2 has been selected by parameters 96.12 User
set I/O mode in1 and 96.13 User set I/O mode in2.
5
User3 IO active User set 3 has been selected by parameters 96.12 User
set I/O mode in1 and 96.13 User set I/O mode in2.
6
User4 IO active User set 4 has been selected by parameters 96.12 User
set I/O mode in1 and 96.13 User set I/O mode in2.
7
User1 backup User set 1 has been saved or loaded. 20
User2 backup User set 2 has been saved or loaded. 21
User3 backup User set 3 has been saved or loaded. 22
User4 backup User set 4 has been saved or loaded. 23
96.11 User set save/load Enables the saving and restoring of up to four custom sets
of parameter settings.
The set that was in use before powering down the drive is
in use after the next power-up.
Notes:
• Some hardware configuration settings, such as I/O
extension module, fieldbus and encoder configuration
parameters (groups 14…16, 47, 50…58 and 92…93)
are not included in user parameter sets.
• Parameter changes made after loading a set are not
automatically stored – they must be saved using this
parameter.
• This parameter cannot be changed while the drive is
running
No action
No action Load or save operation complete; normal operation. 0
User set I/O mode Load user parameter set using parameters 96.12 User set
I/O mode in1 and 96.13 User set I/O mode in2.
1
Load set 1 Load user parameter set 1. 2
Load set 2 Load user parameter set 2. 3
Load set 3 Load user parameter set 3. 4
Load set 4 Load user parameter set 4. 5
Save to set 1 Save user parameter set 1. 18
Save to set 2 Save user parameter set 2. 19
Save to set 3 Save user parameter set 3. 20
Save to set 4 Save user parameter set 4. 21
No. Name/Value Description Default
FbEq 16
