326 Additional parameter data
30.30 Overvoltage control List 0…1 - 1 = 1
30.31 Undervoltage control List 0…1 - 1 = 1
31 Fault functions
31.01 External event 1 source Binary src --1 = 1
31.02 External event 1 type List 0…1 - 1 = 1
31.03 External event 2 source Binary src --1 = 1
31.04 External event 2 type List 0…1 - 1 = 1
31.05 External event 3 source Binary src --1 = 1
31.06 External event 3 type List 0…1 - 1 = 1
31.07 External event 4 source Binary src --1 = 1
31.08 External event 4 type List 0…1 - 1 = 1
31.09 External event 5 source Binary src --1 = 1
31.10 External event 5 type List 0…1 - 1 = 1
31.11 Fault reset selection Binary src --1 = 1
31.12 Autoreset selection PB 0000h…FFFFh - 1 = 1
31.13 Selectable fault Real 0000h…FFFFh - 1 = 1
31.14 Number of trials Real 0…5 - 1 = 1
31.15 Total trials time Real 1.0…600.0 s 10 = 1 s
31.16 Delay time Real 0.0…120.0 s 10 = 1 s
31.19 Motor phase loss List 0…1 - 1 = 1
31.20 Earth fault List 0…2 - 1 = 1
31.21 Supply phase loss List 0…1 - 1 = 1
31.22 STO indication run/stop List 0…3 - 1 = 1
31.23 Wiring or earth fault List 0…1 - 1 = 1
31.24 Stall function List 0…2 - 1 = 1
31.25 Stall current limit Real 0.0…1600.0 % 10 = 1%
31.26 Stall speed limit Real 0.00…10000.00 rpm 100 = 1 rpm
31.27 Stall frequency limit Real 0.00…1000.00 Hz 100 = 1 Hz
31.28 Stall time Real 0…3600 s 1 = 1 s
31.30 Overspeed trip margin Real 0.00…10000.00 rpm 100 = 1 rpm
31.32 Emergency ramp supervision Real 0…300 % 1 = 1%
31.33 Emergency ramp supervision
delay
Real 0…100 s 1 = 1 s
32 Supervision
32.01 Supervision status PB 000…111b - 1 = 1
32.05 Supervision 1 function List 0…6 - 1 = 1
32.06 Supervision 1 action List 0…2 - 1 = 1
32.07 Supervision 1 signal Analog src --1 = 1
32.08 Supervision 1 filter time Real 0.000…30.000 s 1000 = 1 s
32.09 Supervision 1 low Real -21474830.00…
21474830.00
- 100 = 1
No. Name Type Range Unit FbEq32
