360 Fault tracing
64A6 Adaptive program file
incompatible or
corrupted
Adaptive program has faulted. Check the auxiliary code (format XXYY
ZZZZ).
“XX” specifies the number of the state
(00=base program) and “YY” specifies
the number of the function block
(0000=generic error).
”ZZZZ” indicates the problem.
000A Program corrupted or block
non-existent.
Restore the template program or
download the program to the drive.
000C Required block input missing. Check the inputs of the block.
000E Program corrupted or block
non-existent.
Restore the template program or
download the program to the drive.
0011 Program too large. Remove blocks until the error stops.
0012 Program is empty. Correct the program and download it to
the drive.
001C A non-existing parameter or
block is used in the parameter.
Edit the program to correct the parameter
reference, or use an existing block.
001E Output to parameter failed
because the parameter was
write-protected.
Check the parameter reference in the
program.
Check for other sources affecting the
target parameter.
0023 Program file incompatible with
current firmware version.
Adapt the program to current block
library and firmware version.
0024 Program file incompatible with
current firmware version.
Adapt the program to current block
library and firmware version.
Other - Contact your local ABB representative,
quoting the auxiliary code.
64B2 User set fault Loading of user parameter set
failed because
• requested set does not exist
• set is not compatible with
control program
• drive was switched off
during loading.
Ensure that a valid user parameter set
exists. Reload if uncertain.
64E1 Kernel overload Operating system error. Reboot the control unit (using parameter
96.08 Control board boot) or by cycling
power. If the problem persists, contact
your local ABB representative
6581 Parameter system Parameter load or save failed. Try forcing a save using parameter 96.07
Parameter save manually. Retry.
65A1 FBA A parameter
conflict
The drive does not have a
functionality requested by
PLC, or requested functionality
has not been activated.
Check PLC programming.
Check settings of parameter groups 50
Fieldbus adapter (FBA) and 51 FBA A
settings.
6681 EFB comm loss
Programmable fault: 58.14
Communication loss
action
Communication break in
embedded fieldbus (EFB)
communication.
Check the status of the fieldbus master
(online/offline/error etc.).
Check cable connections to the
EIA-485/X5 terminals 29, 30 and 31 on
the control unit.
Code
(hex)
Fault / Aux. code Cause What to do
