EN 13
Attaching and detaching the wall mounting clip
The unit can be mounted either with the wide or the narrow side against the wall. Install the mounting clip on the desired side. See
instructions below for frames A and B. Detach the mounting clip of frames C and D by pulling downward and attach it by pushing
upward.
Detaching the mounting clip, Frames A
and B: Press the two plastic buttons to
detach the upper and lower part of the clip
from each other.
Attaching the mounting clip, Frame A:
Place the two parts as shown and click
them together.
Attaching the mounting clip, Frame B:
Push the two parts between the cooling
fins and click them together.
