Overview of the unit
ACS55 drive controls the speed of a 3-phase AC induction motor.
Input terminals, page 17
Power on LED, page 21
Fault LED, page 21
Control potentiometers, page 16
Analogue input signal selector
(voltage/current), page 18
Mounting clip, pages 12 - 13
Relay output terminals, page 18
Motor cable terminals, page 17. Sliding
cover provides additional insulation. Slide
the cover left to close.
Protective earth (PE), page 17
DIP switches, page 14
Control cable terminals, page 18
Clamp plate, page 19 (EMC units only)
Motor cable shield, page 17
DriveConfig kit interface, page 24
