No. Name/Value Description FbEq
Bit Name Value Information Log. Par.
(continued)
9 Jogging 1 1 Activate Jogging 1. See section Jogging on page 64.
OR 10.07
0 Jogging 1 disabled.
10 Jogging 2 1 Activate Jogging 2. See section Jogging on page 64.
OR 10.08
0 Jogging 2 disabled.
11 Remote
cmd
1 Fieldbus control enabled.
––
0 Fieldbus control disabled.
12 Ramp out
0
1 Force output of Ramp Function Generator to zero. The
drive ramps to a stop (current and DC voltage limits are
in force).
––
0 No action.
13 Ramp hold 1 Halt ramping (Ramp Function Generator output held).
––
0 No action.
14 Ramp in 0 1 Force input of Ramp Function Generator to zero.
––
0 No action.
15 Ext1 / Ext2 1 Switch to external control location EXT2.
OR 12.01
0 Switch to external control location EXT1.
16 Req
startinh
1 Activate start inhibit.
––
0 No start inhibit.
17 Local ctl 1 Request local control for Control Word. Used when the
drive is controlled from a PC tool or panel or local
fieldbus.
• Local fieldbus: Transfer to fieldbus local control
(control through Control Word or reference).
Fieldbus steals the control.
• Panel or PC tool: Transfer to local control.
––
0 Request external control.
18 FbLocal ref 1 Request fieldbus local control.
––
0 No fieldbus local control.
19…27 Reserved
28 CW B28 Freely programmable control bits. See parameters
50.08…50.11.
––
29 CW B29
30 CW B30
31 CW B31
