ABB ACS850 - Page 283

Additional parameter data 283
48.07 Br temp alarmlim REAL24 16 0…150 % 95%
49 Data storage
49.01 Data storage1 UINT32 16 -32768…32768 - 0
49.02 Data storage2 UINT32 16 -32768…32768 - 0
49.03 Data storage3 UINT32 16 -32768…32768 - 0
49.04 Data storage4 UINT32 16 -32768…32768 - 0
49.05 Data storage5 UINT32 32 -2147483647 … 2147483647 - 0
49.06 Data storage6 UINT32 32 -2147483647 … 2147483647 - 0
49.07 Data storage7 UINT32 32 -2147483647 … 2147483647 - 0
49.08 Data storage8 UINT32 32 -2147483647 … 2147483647 - 0
50 Fieldbus
50.01 Fba enable enum 16 0…1 - Disable
50.02 Comm loss func enum 16 0…3 - No
50.03 Comm loss t out UINT32 16 0.3…6553.5 s 0.3 s
50.04 Fb ref1 modesel enum 16 0…2 - Speed
50.05 Fb ref2 modesel enum 16 0…2 - Torque
50.06 Fb act1 tr src Val pointer 32 - - P.01.01
50.07 Fb act2 tr src Val pointer 32 - - P.01.06
50.08 Fb sw b12 src Bit pointer 32 - - C.FALSE
50.09 Fb sw b13 src Bit pointer 32 - - C.FALSE
50.10 Fb sw b14 src Bit pointer 32 - - C.FALSE
50.11 Fb sw b15 src Bit pointer 32 - - C.FALSE
50.12 FB comm speed enum 16 0…3 - High
50.15 Fb cw used Val pointer 32 - - P.02.22
50.20 Fb main sw func Pb 16 0b000…0b111 - 0b001
51 FBA settings
51.01 FBA type UINT32 16 0…65536 - 0
51.02 FBA par2 UINT32 16 0…65536 - 0
…… … …. … … …
51.26 FBA par26 UINT32 16 0…65536 - 0
51.27 FBA par refresh enum 16 0…1 - Done
51.28 Par table ver UINT32 16 0…65536 - -
51.29 Drive type code UINT32 16 0…65536 - -
51.30 Mapping file ver UINT32 16 0…65536 - -
51.31 D2FBA comm sta enum 16 0…6 - Idle
51.32 FBA comm sw ver UINT32 16 0…65536 - -
51.33 FBA appl sw ver UINT32 16 0…65536 - -
52 FBA data in
52.01 FBA data in1 UINT32 16 0…9999 - 0
…… … … … … …
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
