284 Additional parameter data
52.12 FBA data in12 UINT32 16 0…9999 - 0
53 FBA data out
53.01 FBA data out1 UINT32 16 0…9999 - 0
…… … … … … …
53.12 FBA data out12 UINT32 16 0…9999 - 0
56 Panel display
56.01 Signal1 param UINT32 00.00 … 255.255 - 01.03
56.02 Signal2 param UINT32 00.00 … 255.255 - 01.04
56.03 Signal3 param UINT32 00.00 … 255.255 - 01.06
56.04 Signal1 mode INT32 -1…3 - Normal
56.05 Signal2 mode INT32 -1…3 - Normal
56.06 Signal3 mode INT32 -1…3 - Normal
56.07 Local ref unit UINT32 0…1 - rpm
56.08 Speed filt time REAL 32 0…10000 ms 250 ms
56.09 Torque filt time REAL 32 0…10000 ms 100 ms
57 D2D communication
57.01 Link mode enum 16 0…2 - Disabled
57.02 Comm loss func enum 16 0…2 - Alarm
57.03 Node address UINT32 16 1…62 - 1
57.04 Follower mask 1 UINT32 32 0h00000000 … 0h7FFFFFFF - 0h00000000
57.05 Follower mask 2 UINT32 32 0h00000000 … 0h7FFFFFFF - 0h00000000
57.06 Ref 1 src Val pointer 32 - - P.03.05
57.07 Ref 2 src Val pointer 32 - - P.03.13
57.08 Follower cw src Val pointer 32 - - P.02.31
57.11 Ref1 msg type enum 16 0…1 - Broadcast
57.12 Ref1 mc group UINT32 16 0…62 - 0
57.13 Next ref1 mc grp UINT32 16 0…62 - 0
57.14 Nr ref1 mc grps UINT32 16 1…62 - 1
57.15 D2D com port enum 16 0…3 - on-board
58 Embedded Modbus
58.01 Protocol ena sel UINT32 32 0…1 - Modbus RTU
58.03 Node address UINT32 32 0…247 - 1
58.04 Baud rate UINT32 32 0…6 - 9600
58.05 Parity UINT32 32 0…3 - 8 none 1
58.06 Control profile UINT32 32 0…3 - ABB Enhanced
58.07 Comm loss t out UINT32 32 0…60000 ms 600
58.08 Comm loss mode UINT32 32 0…2 - None
58.09 Comm loss action UINT32 32 0…3 - None
58.10 Refresh settings UINT32 32 0…1 - Done
58.11 Reference scale Pb 16 1…65535 - 100
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
