Additional parameter data 285
58.15 Comm diagnostics Pb 16 0x0000…0xFFFF - 0x0000
58.16 Received packets UINT32 32 0…65535 - 0
58.17 Transm packets UINT32 32 0…65535 - 0
58.18 All packets UINT16 16 0…65535 - 0
58.19 UART errors UINT16 16 0…65535 - 0
58.20 CRC errors UINT16 16 0…65535 - 0
58.21 Raw CW LSW Pb 16 0x0000…0xFFFF - 0x0000
58.22 Raw CW MSW Pb 16 0x0000…0xFFFF - 0x0000
58.23 Raw SW LSW Pb 16 0x0000…0xFFFF - 0x0000
58.24 Raw SW MSW Pb 16 0x0000…0xFFFF - 0x0000
58.25 Raw Ref 1 LSW Pb 16 0x0000…0xFFFF - 0x0000
58.26 Raw Ref 1 MSW Pb 16 0x0000…0xFFFF - 0x0000
58.27 Raw Ref 2 LSW Pb 16 0x0000…0xFFFF - 0x0000
58.28 Raw Ref 2 MSW Pb 16 0x0000…0xFFFF - 0x0000
58.30 Transmit delay UINT16 16 0…65535 ms 0
58.31 Ret app errors UINT16 16 0…1 - Yes
58.32 Word order UINT32 32 0…1 - LSW MSW
58.35 Data I/O 1 UINT16 16 0…9999 - 0
58.36 Data I/O 2 UINT16 16 0…9999 - 0
…… … … … … …
58.58 Data I/O 24 UINT16 16 0…9999 - 0
64 Load analyzer
64.01 PVL signal Val pointer 32 - - Power inu
64.02 PVL filt time REAL 16 0…120 s 2.00 s
64.03 Reset loggers Bit pointer 32 - - C.FALSE
64.04 AL signal Val pointer 32 - - Power motor
64.05 AL signal base REAL 32 0…32768 - 100.00
64.06 PVL peak value1 REAL 32 -32768…32768 - -
64.07 Date of peak UINT32 32 01.01.80… d -
64.08 Time of peak UINT32 32 00:00:00…23:59:59 s -
64.09 Current at peak REAL 32 -32768…32768 A -
64.10 Dc volt at peak REAL 32 0…2000 V -
64.11 Speed at peak REAL 32 -32768…32768 rpm -
64.12 Date of reset UINT32 32 01.01.80… d -
64.13 Time of reset UINT32 32 00:00:00…23:59:59 s -
64.14 AL1 0 to 10% REAL 16 0…100 % -
64.15 AL1 10 to 20% REAL 16 0…100 % -
64.16 AL1 20 to 30% REAL 16 0…100 % -
64.17 AL1 30 to 40% REAL 16 0…100 % -
64.18 AL1 40 to 50% REAL 16 0…100 % -
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
