286 Additional parameter data
64.19 AL1 50 to 60% REAL 16 0…100 % -
64.20 AL1 60 to 70% REAL 16 0…100 % -
64.21 AL1 70 to 80% REAL 16 0…100 % -
64.22 AL1 80 to 90% REAL 16 0…100 % -
64.23 AL1 over 90% REAL 16 0…100 % -
64.24 AL2 0 to 10% REAL 16 0…100 % -
64.25 AL2 10 to 20% REAL 16 0…100 % -
64.26 AL2 20 to 30% REAL 16 0…100 % -
64.27 AL2 30 to 40% REAL 16 0…100 % -
64.28 AL2 40 to 50% REAL 16 0…100 % -
64.29 AL2 50 to 60% REAL 16 0…100 % -
64.30 AL2 60 to 70% REAL 16 0…100 % -
64.31 AL2 70 to 80% REAL 16 0…100 % -
64.32 AL2 80 to 90% REAL 16 0…100 % -
64.33 AL2 over 90% REAL 16 0…100 % -
90 Enc module sel
90.01 Encoder 1 sel enum 16 0…7 - None
90.02 Encoder 2 sel enum 16 0…7 - None
90.04 TTL echo sel enum 16 0…5 - Disabled
90.05 Enc cable fault enum 16 0…2 - Fault
90.10 Enc par refresh enum 16 0…1 - Done
91 Absol enc conf
91.01 Sine cosine nr UINT32 16 0…65535 - 0
91.02 Abs enc interf enum 16 0…5 - None
91.03 Rev count bits UINT32 16 0…32 - 0
91.04 Pos data bits UINT32 16 0…32 - 0
91.05 Refmark ena enum 16 0…1 - False
91.10 Hiperface parity enum 16 0…1 - Odd
91.11 Hiperf baudrate enum 16 0…3 - 9600
91.12 Hiperf node addr UINT32 16 0…255 - 64
91.20 SSI clock cycles UINT32 16 2…127 - 2
91.21 SSI position msb UINT32 16 1…126 - 1
91.22 SSI revol msb UINT32 16 1…126 - 1
91.23 SSI data format enum 16 0…1 - binary
91.24 SSI baud rate enum 16 0…5 - 100 kbit/s
91.25 SSI mode enum 16 0…1 - Initial pos.
91.26 SSI transmit cyc enum 16 0…5 - 100 µs
91.27 SSI zero phase enum 16 0…3 - 315-45 deg
91.30 Endat mode enum 16 0…1 - Initial pos.
91.31 Endat max calc enum 16 0…3 - 50 ms
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
