Description
Allows you to manage the settings of the selected conveyor.Setting
When you select Setting, the Conveyor Setting window is displayed.
More details about managing a selected conveyor is available in the
section Adding Conveyor on page 85.
Allows you to delete the selected conveyor.Delete
Allows you to change the name of the selected conveyor.Rename
Allows you to manage the hotspots.Hotspots...
When you select Hotspots..., the Set Conveyor hotspots window
is displayed. See the following section for more details about the
Set Conveyor hotspots window.
Note
The hotspot is a saved location on the conveyor. A hotspot is used
to define where on the conveyor the flow shall be generated. There
is always a default hotspot, Hotspot0, located at the beginning of
the conveyor. If the flow appears at a wrong location, modify the
hotspot location to adjust it.
Allows you to examine the selected conveyor in the Station view.Examine
The following figure and table provides details about the Set Conveyor hotspots
window.
xx1800001395
Description
Displays the available hotspots.Hotspots list
Allows you define the position of the hotspot.Position X Y Z
Continues on next page
Application manual - PickMaster® Twin - PowerPac 61
3HAC064218-001 Revision: B
© Copyright 2021 ABB. All rights reserved.
3 Navigating PickMaster PowerPac
3.4.1 Cell
Continued
