SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 79
Select the application using the digital inputs
Only if an appropriate plug
-in card is
Only if an appropriate plug
-in card is
Only if an appropriate plug
-in card is
61. Use to call up the edit mode.
62. Use / to assign the applications to the respective
digital inputs.
63. Confirm the selection with .
Select measuring ranges and units
Mass Flow [%]
has been selected
as the process value for a current,
frequency or pulse output.
64. Use to call up the edit mode.
65. Use / to select the unit for mass flow measurement.
66. Confirm the selection with .
Mass Flow [%]
has been selected
as the process value for a current,
frequency or pulse output.
67. Use to call up the edit mode.
68. Use / to set the desired measuring range for mass
flow measurement.
69. Confirm the selection with .
70. Use to call up the edit mode.
71. Use / to select the desired unit for volume flow
measurement.
72. Confirm the selection with .
73. Use to call up the edit mode.
74. Use / to select the desired standard state for volume
flow measurement.
75. Confirm the selection with .
Volume Flow [%] has been
selected as the process value for a
current, frequency or pulse output.
76. Use to call up the edit mode.
77. Use / to set the desired measuring range for volume
flow measurement.
78. Confirm the selection with .
