MC97F6108A User’s manual 11. PPG (Programmable Pulse Generator)
123
ATPMINLR (Auto Period Mode Min Period Low Register) : 2F06H
7
6
5
4
3
2
1
0
ATPMINLR7
ATPMINLR6
ATPMINLR5
ATPMINLR4
ATPMINLR3
ATPMINLR2
ATPMINLR1
ATPMINLR0
R / W
R / W
R / W
R / W
R / W
R / W
R / W
R / W
Initial value: 00H
ATPMINLR[7:0]
Auto Period Mode Min Period Low Register
ATPMINHR (Auto Period Mode Min Period High Register) : 2F07H
7
6
5
4
3
2
1
0
ATPMINHR7
ATPMINHR6
ATPMINHR5
ATPMINHR4
ATPMINHR3
ATPMINHR2
ATPMINHR1
ATPMINHR0
R / W
R / W
R / W
R / W
R / W
R / W
R / W
R / W
Initial value: 00H
ATPMINHR[7:0]
Auto Period Mode Min Period High Register
OFFCR (PPG Off-Time Control Register) : B9H
7
6
5
4
3
2
1
0
OFMAX
OFMIN
0
-
-
-
-
-
R/W
R/W
R/W
-
-
-
-
-
Initial value: 00H
OFMAX
Enable or Disable PPG max off-time.
0
Disable
1
Enable
OFMIN
Enable or Disable PPG min off time
0
Disable
1
Enable
OFFMAXLR (PPG Off Time Max Period Low Register) : 2F0CH
7
6
5
4
3
2
1
0
OFFMAXLR7
OFFMAXLR6
OFFMAXLR5
OFFMAXLR4
OFFMAXLR3
OFFMAXLR2
OFFMAXLR1
OFFMAXLR0
R / W
R / W
R / W
R / W
R / W
R / W
R / W
R / W
Initial value: 00H
OFFMAXLR[7:0]
PPG Off Time Max Period Low Register
OFFMAXHR (PPG Off Time Max Period High Register) : 2F0DH
7
6
5
4
3
2
1
0
OFFMAXHR7
OFFMAXHR6
OFFMAXHR5
OFFMAXHR4
OFFMAXHR3
OFFMAXHR2
OFFMAXHR1
OFFMAXHR0
R / W
R / W
R / W
R / W
R / W
R / W
R / W
R / W
Initial value: 00H
OFFMAXHR[7:0]
PPG Off Time Max Period High Register
OFFMINLR (PPG Off Time Min Period Low Register) : 2F0EH
7
6
5
4
3
2
1
0
OFFMINLR7
OFFMINLR6
OFFMINLR5
OFFMINLR4
OFFMINLR3
OFFMINLR2
OFFMINLR1
OFFMINLR0
R / W
R / W
R / W
R / W
R / W
R / W
R / W
R / W
Initial value: 00H
OFFMINLR[7:0]
PPG Off Time Min Period Low Register
