MC97F6108A User’s manual 12. Analog comparator and OP-AMP
131
CA_REG4 (Comparator Amp Register 4) : 2F34H
7
6
5
4
3
2
1
0
CMPEN
HYSL_EN3
HYSL_EN2
HYSL_EN1
C2INPen
C1INPen
C0INPen
C0INNen
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
CMPEN
Control comparator
0
All Comparator Disable
1
All Comparator Enable
HYSL_EN3
Control Comparator 3 hysteresis
0
Disable
1
Enable
HYSL_EN2
Control Comparator 1, 2, 4 hysteresis
0
Disable
1
Enable
HYSL_EN1
Control Comparator 0 hysteresis
0
Disable
1
Enable
C2INPen
Control CMP2_IN_P port
0
Comparator 2 input from CMP2_IN_P port disable
1
Comparator 2 input from CMP2_IN_P port enable
C1INPen
Control CMP1_IN_P port
0
Comparator 1 input from CMP1_IN_P port disable
1
Comparator 1 input from CMP1_IN_P port enable
C0INPen
Control CMP0_IN_P port
0
Comparator 0 input from CMP0_IN_P port disable
1
Comparator 0 input from CMP0_IN_P port enable
C0INNen
Control CMP0_IN_N port
0
Comparator 0 input from CMP0_IN_N port disable
1
Comparator 0 input from CMP0_IN_N port enable
