ActronAir ELY620T - Page 48

48
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Installation and Commissioning Guide
Split Tri-Capacity
On screen C1, set the Fan Mode to operate in either Continuous or Auto cycle (Auto cycle will cycle the
indoor fans on/off with the compressor).
Select Auto Cycle or Continuous Indoor Fan operation
Heat / Cool C1
Mode: AUTO CHANGE OVER
Fan mode: Auto cycle
On screen Gfc13, set the Type of fans fitted Supply to ACTRON A2FB.
G. Service Gf. Service settings Gfc. Thermoregulation Gfc13. S. Configuration
ACTRON A2FB
S. Conguration Gfc13
Type of fans tted :
Supply : ACTRON A2FB
Outdoor : 2 SPEED AC
Outdoor Init Speed
OF1: 60.0% OF23: 60.0%
Econ. cycle tted : Yes
Econ. type: MODULATE
On screen Gfc4, set the Supply Fan Medium Speed to the required indoor fan speed.
G. Service Gfc. Service Settings Gfc. Thermoregulation Gfc4. Thermoregulat.
Required Indoor Fan Speed
Thermoregulat. Gfc4
Supply Fan
Minimum speed: 49.0%
Medium speed: 71.9%
Maximum speed: 90.0%
Supply Fan Temp.
Minimum Temp. 5.0
o
C
Maximum Temp. 50.0
o
C
NOTES
• Minimum and Maximum fan speeds are factory default settings.
• Medium fan speed is the nominal operating fan speed which can be adjusted between the minimum and maximum speed.
Ensure that One Speed fan is set to Yes
G. Service Gfc. Service Settings Gfc. Thermoregulation Gfc5. Thermoregulat.
YES
Thermoregulat. Gfc5
Supply fan Gen. 3 :
Supply fan Cont in :
Cycle on de-ice :
One Speed fan :
Supply fan Run on :
Heat start delay :
No
Yes
Yes
Yes
30s
20s
