Leak
value display
•
On the
remote
control:
10
-2
Digital display
10
-3
10
-4
10
-5
10
-6
Analog display
When the bargraph zoom is ON, the leak value
display is different. It
shows
2
decades
of signal
as compare to the entire leak range when the
bargraph zoom is off.
C
510
10
-7
10
-8
10
-9
10
-10
10
-11
10
-12
mbar.l/s
Ending
a
test
cycle
or
VENT
STDBY
•
In standby mode the
user
interface
shows
the leak
detector
helium
background value.
Note: If the cycle end function is activated, the
test
cycle end is
different.
Cycle
end
function
C
530
Ticket
If memo function activated, and a printer
connected
to the leak
detector, a
result
ticket is printed automatically:
example
6
B
320.
Venting the part or
installation
tested
At the end of a
test
cycle, 2
possibilities
are available:
•
venting (inlet of the leak
detector
is back to
atmospheric
pressure)
•
not venting (keeping under
vacuum)
the part or
tested
installation
tested remains
under vacuum.
Inlet
vent
C
500
