Adixen ASM GRAPH D+ - Analog Display; Remote Control and Control Panel; Zero Function and Bargraph Zoom

2 /2
C 510
Bargraph zoom
blinking led = reject point
(1 + 1) decades
1 decade
GB 01265
-
Edition 03
-
March
04
Analog display
When a bargraph zoom is activated, use the helium signal zero scale:
a blinking led indicates the reject point.
Remote control
& control panel
10
-2
10
-3
10
-12
10
-11
10
-10
10
-9
10
-8
10
-7
10
-6
10
-5
10
-4
10
-3
10
-2
COR ZERO
10
-4
10
-5
blinking led = reject point
(1 + 1) decades 1 decade
INLET
10
3
10
2
10
1
1
10
-1
10
-2
TEST
HIGH
SNIF
VENT
10
-6
10
-7
10
-8
10
-9
10
-10
10
-11
Control panel
The helium signal zero scale displays
the leak value in 2 colors following
the
measured leak value:
10
-3
10
-1 2
mbar mbar.l/s
CYCLE
AUTO CAL ZERO
• if the measured leak value is under
the reject point, the flashing leds are
green,
• if the measured leak value exceeds
the reject point, the flashing leds are
red (and the blinking led orange).
Reject point C 211
Remote control
Zero function &
Bargraph zoom
When bargraph zoom and zero functions are ON in the same time,
the operator
must read measured leak value in this way as follow:
• digital display
The leak value displayed is the value corrected with zero function.
Zero function C 540
• analog display
Use the helium signal zero scale.
The analog display is the actual bargraph zoom display (see above).
