Adixen ASM GRAPH D+ - Chapter B INSTALLATION

Installation
B
ASM GRAPH - ASM GRAPH D
GB 00214 -
Edition
05 -
June
08
ASM 142 - ASM 142 D
Preliminary
remarks
ASM GRAPH D+ User ’ s Manual
Detailed contents
Throughout this User’s Manual, you could find this type of message
“Summary of screen C 140”: it refers to a specific chapter of the
User’s Manual. Please read it for further information.
B 100 Safety instr uctions
- Generalities
- Pump labels
- Leak detector labels
- Contact the manufacturer in case of emergency
B 110 Unpacking - Storage - T ranspor tation
- Unpacking
- Precautionary measures for the leak detector transportation
- Supplies
- Storage
- Fixed mounting
- T ranspor t
- Precautionary measures for the leak detector installation
B 200 Neutral gas purge and inlet vent connection
- Products concerned
- Connection to the leak detector
- Use
- Gas characteristics
B 201 Neutral gas purge installation (accessory) - ASM 142
- Object
- Material
- Installation
B 210 Connecting the detector to the installation
B 211 Connecting the detector to the installation: ASM Graph D+
B 300 Controlling the detector with the I/O interface
- Purpose of the I/O interface
- Location of the I/O interface
- Prepare the connector wiring
- The controls (inputs)
- The signals (outputs)
- 24 V DC Power supply
