Animated synoptic
Please refer to the “Change of interface” paragraph to reach it.
Synoptic reading
4
1
2
3
1 2 3 4
Etat du détecteur
interactive components
Valve closed Inactive canalization
Valve opened Active canalization: gas flow
When you press on the interactive components, you have a section
of the
component or its operating principle. To return to the original
illustration, press again on the component.
Example
Note:
• The synoptic is personalized for each leak detector.
